LB-HD65 WEATHER STATION
The multi-parameter sensor integrates multiple sensor parameters, RS485 signal output, standard Modbus-RTU protocol, and has good consistency and stability. It has been finely calibrated during production, and the calibration data is stored in the internal memory. The sensor has digital output and is fully interchangeable. It does not require complex verification and calibration processes. It is outstanding in terms of measurement accuracy, linearity, repeatability, interchangeability, consistency, etc. It is designed with a temperature compensation circuit and can be used at different ambient temperatures. It is very suitable for monitoring air temperature and humidity , pressure, wind speed, wind direction, illumination.
Parameter | Resolution | Range | Accuracy |
Wind speed range | 0.1 m/s | 0 to 70 m/s | +- 0.3 m/s |
Wind direction | 0.1º | 0 to 360.0° | +-1° |
Air temperature | 0.1℃ | - 40℃ to 80℃ | +- 0.2℃ |
Relative humidity | 0.1%RH | 0 to 100.0%RH | +- 3%RH |
Air Pressure | 0.1 hpa | 300-1100 hPa | +- 0.1 hPa |
Brightness | 1 Lux | 1 - 150 kLux | +- 3% FS |
Precipitation | Resolution 0.2 mm | 0-4 mm/min | +- 2% |
Total Radiation | 0.1 w/m^2 | 0-2000 w/m^2 | +- 2% |
